電動機簡介
該電機是專為螺桿壓縮機配套而設計制造的，機座為高強度鑄鐵基座，接線盒位置分機座頂部或側部?jī)煞N。機座號為H132-H315，安裝方式分為IMB3、IMB5，服務系數為SF=1.15或SF=1.25，絕緣等級為F級，在額定負載時溫升按B級考核。在系數負載時，溫升按90K考核，軸承溫度不超過95℃。
中心高（H）：132-400mm；
功率范圍（Power）：5.5-500kW
● 本系列壓縮機專用三相異步電動機是我公司專門考慮壓縮機特殊工況而開發設計的電動機，中心高從H132~H400，功率從5.5-500kW，絕緣等級為F級，額定時溫升按B級考核，一般服務系數下的溫升按F級考核，服務系數有SF：1.10、1.15、1.20等多種服務系數（即電機實際功率可達到額定功率乘以此服務系數）。
● 本系列電動機采用特殊的軸承配置，確保軸承能長期正常工作。考慮電機的電纜直接和壓縮機的電控箱連接，可以為客戶做加長引出線的配置，采用電纜護套管保護，兩端帶有管螺套。本系列電機具有高效、節能等優點，性能穩定，適用于壓縮機長期連續工作。
● 本系列電動機性能和安裝尺寸符合IEC60034標準、DIN42673標準和GB755標準及有關專業技術標準。且公司已多次通過ISO9001國際質量體系認證。從訂單、開發、制造、檢驗、銷售、服務全過程按照ISO9001質量體系的要求進行控制。
● 本系列電動機供電電源為三相工頻50Hz（或根據需要設計為變頻電動機）；電源電壓等級為380V，也可根據客戶需要設計為400V、500V、550V等。
● 本系列電動機一般接法：3KW以下為Y接法，4KW以上為△接法。
● 本系列工作環境：溫度環境40℃，海拔不超過1000m，特殊環境條件請用戶在訂貨時注明。
● 本系列電動機采用國際通用的防護等級IP54或IP55。
● 本系列電動機工作方式為連續工作制（S1）。
● 本系列電動機采用高導磁低損耗硅鋼片，因而損耗低、效率高。
● 本系列電動機基本通風方式為IC411或IC416，冷卻散熱條件比較成熟。
● 本系列電動機具有高效、節能、低振動、低噪聲、性能可靠、安裝維護方便等特點。
Motor introduction
The motor is designed and manufactured for the screw compressor. The base is a high-strength cast iron base. The junction box is located at the top or side of the extension base. The frame number is H132-H315, the installation method is divided into IMB3 and IMB5, the service factor is SF=1.15 or SF=1.25, the insulation level is F grade, and the temperature rise at the rated load is evaluated according to the B grade. When the coefficient is loaded, the temperature rise is evaluated by 90K, and the bearing temperature does not exceed 95 °C.
Center height (H): 132-400mm;
Power range (Power): 5.5-500kW
● This series of compressor special three-phase asynchronous motor is developed and designed by our company specially considering the special working conditions of the compressor. The center height is from H132~H400, the power is from 5.5-500kW, the insulation grade is F grade, and the rated temperature rise is pressed. Class B assessment, the temperature rise under the general service factor is assessed according to the F level, and the service factor is SF: 1.10, 1.15, 1.20 and other service factors (ie, the actual power of the motor can reach the rated power multiplied by the service factor).
● This series of motors uses a special bearing configuration to ensure that the bearings can work normally for a long time. Considering that the cable of the motor is directly connected to the electric control box of the compressor, the configuration of the extension lead wire can be made for the customer, and the cable sheath tube is used for protection, and the pipe thread sleeve is provided at both ends. This series of motors has the advantages of high efficiency, energy saving, stable performance, and is suitable for long-term continuous operation of the compressor.
● The performance and installation dimensions of this series of motors comply with IEC60034 standard, DIN42673 standard and GB755 standard and related professional technical standards. And the company has passed ISO9001 international quality system certification. The whole process of order, development, manufacturing, inspection, sales and service is controlled according to the requirements of ISO9001 quality system.
● This series of motor power supply is three-phase power frequency 50Hz (or designed as variable frequency motor according to need); the power supply voltage level is 380V, and can also be designed as 400V, 500V, 550V according to customer needs.
● This series of motors is generally connected: Y connection is below 3KW, and △ connection is above 4KW.
● Working environment of this series: temperature environment 40 °C, altitude not exceeding 1000m, special environmental conditions, please specify when ordering.
● This series of motors adopts the international protection grade IP54 or IP55.
● This series of motors works in continuous operation (S1).
● This series of motors uses high magnetic permeability and low loss silicon steel sheets, resulting in low loss and high efficiency.
● The basic ventilation mode of this series of motors is IC411 or IC416, and the cooling and cooling conditions are relatively mature.
● This series of motors has the characteristics of high efficiency, energy saving, low vibration, low noise, reliable performance, convenient installation and maintenance.
