技術特性
全封閉自扇冷卻式三相異步電機，設計要求符合IEC、GB等相關要求；
外殼材料為灰鑄鐵；
電動機效率達到GB18613-2012標準能效等級一級及IEC60034-30標磚的IE4效率等級要求；
特定繞組設計可支持多種電壓（50HZ或60HZ）;
可承受1.5倍額定電流達2分鐘（IEC60034-1）;
可選配防潮加熱帶（空間加熱器）；
可選配PTC或PT100等熱敏元件進行繞組或軸承熱保護。
Technical Features
Fully enclosed self-fan cooling three-phase asynchronous motor, design requirements in line with IEC, GB and other related requirements;
The outer casing material is gray cast iron;
Motor efficiency meets the GB18613-2012 standard energy efficiency rating and IE60034-30 standard IE4 efficiency rating requirements;
The specific winding design can support a variety of voltages (50HZ or 60HZ);
Can withstand 1.5 times rated current for 2 minutes (IEC60034-1);
Optional with moisture-proof heating belt (space heater);
Optional PTC or PT100 thermal elements for winding or bearing thermal protection.
產品優勢
效率提高
通過新型的繞組設計，并采用損耗低的硅鋼材料，減少電機的損耗，提高電機效率，節約用電為客戶提高經濟效益并有利于減少能源消費，保護環境；
可靠的質量和優良的電機性能
為確保良好的絕緣性能，增加電機的使用壽命，標準電機采用F級絕緣系統并按B級考核（80k）；
電壓、效率
標準電機的供電電壓和頻率符合IEC60034-1標準中規定的A類電壓和頻率誤差要求，充許電壓偏差為±5%，頻率偏差±2%；
額定輸出
額定輸出是指符合IEC60034-1標準的要求，冷卻介質溫度（CT）為40℃，設備安裝地點的海拔高度在1000m以下的情況，連續工作可以充許的輸出。根據IEC60034-1標準的要求，該系列電動機在額定電壓和頻率下能承受1.5倍額定電流持續2分鐘。
Product Advantage
Improve efficiency
Through the new winding design, and the use of low-loss silicon steel materials, reduce motor losses, improve motor efficiency, save electricity for customers to improve economic efficiency and help reduce energy consumption, protect the environment; Br /> Reliable quality and excellent motor performance
To ensure good insulation performance, increase the service life of the motor, the standard motor uses Class F insulation system and is assessed according to Class B (80k);
Voltage, efficiency
The standard motor supply voltage and frequency meet the Class A voltage and frequency error requirements specified in the IEC60034-1 standard, the allowable voltage deviation is ± 5%, frequency deviation ± 2%; /> rated output
Rated output refers to the requirements of IEC60034-1 standard, the cooling medium temperature (CT) is 40 °C, the altitude of the equipment installation location is below 1000m, continuous output can be allowed to output. According to the requirements of IEC60034-1, this series of motors can withstand 1.5 times the rated current for 2 minutes at rated voltage and frequency.
應用領域
可用于驅動各種通用機械如機床、空壓機、水泵、風機、減速機、傳輸帶、礦山機械、冶金設備等。不含易燃，易爆或腐蝕性氣體場合。
Applications
Can be used to drive a variety of general machinery such as machine tools, air compressors, pumps, fans, reducers, conveyor belts, mining machinery, metallurgical equipment. Contains no flammable, explosive or corrosive gases.
